PyTorch Model Deployment on Edge Devices - Complete Code Guide

Prerequisites

# Install required packages
pip install torch torchvision
pip install torch-model-archiver
pip install onnx onnxruntime
pip install tensorflow  # for TensorFlow Lite conversion

1. Model Optimization

Quantization

import torch
import torch.quantization as quantization
from torch.quantization import get_default_qconfig
import torchvision.models as models

# Load your trained model
model = models.resnet18(pretrained=True)
model.eval()

# Post-training quantization (easiest method)
def post_training_quantization(model, sample_data):
    """
    Apply post-training quantization to reduce model size
    """
    # Set model to evaluation mode
    model.eval()

    # Fuse conv, bn and relu
    model_fused = torch.quantization.fuse_modules(model, [['conv1', 'bn1', 'relu']])

    # Specify quantization configuration
    model_fused.qconfig = torch.quantization.get_default_qconfig('fbgemm')

    # Prepare the model for quantization
    model_prepared = torch.quantization.prepare(model_fused)

    # Calibrate with sample data
    with torch.no_grad():
        for data in sample_data:
            model_prepared(data)

    # Convert to quantized model
    quantized_model = torch.quantization.convert(model_prepared)

    return quantized_model

# Example usage
sample_data = [torch.randn(1, 3, 224, 224) for _ in range(100)]
quantized_model = post_training_quantization(model, sample_data)

Pruning

import torch.nn.utils.prune as prune

def prune_model(model, pruning_amount=0.3):
    """
    Apply magnitude-based pruning to reduce model complexity
    """
    parameters_to_prune = []

    # Collect all conv and linear layers
    for name, module in model.named_modules():
        if isinstance(module, (torch.nn.Conv2d, torch.nn.Linear)):
            parameters_to_prune.append((module, 'weight'))

    # Apply global magnitude pruning
    prune.global_unstructured(
        parameters_to_prune,
        pruning_method=prune.L1Unstructured,
        amount=pruning_amount,
    )

    # Remove pruning reparameterization to make pruning permanent
    for module, param in parameters_to_prune:
        prune.remove(module, param)

    return model

# Apply pruning
pruned_model = prune_model(model.copy(), pruning_amount=0.3)

2. Model Conversion

Convert to TorchScript

def convert_to_torchscript(model, sample_input, save_path):
    """
    Convert PyTorch model to TorchScript for deployment
    """
    model.eval()

    # Method 1: Tracing (recommended for models without control flow)
    try:
        traced_model = torch.jit.trace(model, sample_input)
        traced_model.save(save_path)
        print(f"Model traced and saved to {save_path}")
        return traced_model
    except Exception as e:
        print(f"Tracing failed: {e}")

        # Method 2: Scripting (for models with control flow)
        try:
            scripted_model = torch.jit.script(model)
            scripted_model.save(save_path)
            print(f"Model scripted and saved to {save_path}")
            return scripted_model
        except Exception as e:
            print(f"Scripting also failed: {e}")
            return None

# Example usage
sample_input = torch.randn(1, 3, 224, 224)
torchscript_model = convert_to_torchscript(model, sample_input, "model.pt")

Convert to ONNX

import onnx
import onnxruntime as ort

def convert_to_onnx(model, sample_input, onnx_path):
    """
    Convert PyTorch model to ONNX format
    """
    model.eval()

    torch.onnx.export(
        model,                      # model being run
        sample_input,               # model input
        onnx_path,                 # where to save the model
        export_params=True,         # store the trained parameter weights
        opset_version=11,          # ONNX version to export to
        do_constant_folding=True,   # optimize constant folding
        input_names=['input'],      # model's input names
        output_names=['output'],    # model's output names
        dynamic_axes={
            'input': {0: 'batch_size'},
            'output': {0: 'batch_size'}
        }
    )

    # Verify the ONNX model
    onnx_model = onnx.load(onnx_path)
    onnx.checker.check_model(onnx_model)
    print(f"ONNX model saved and verified at {onnx_path}")

# Convert to ONNX
convert_to_onnx(model, sample_input, "model.onnx")

# Test ONNX Runtime inference
def test_onnx_inference(onnx_path, sample_input):
    """Test ONNX model inference"""
    ort_session = ort.InferenceSession(onnx_path)

    # Convert input to numpy
    input_np = sample_input.numpy()

    # Run inference
    outputs = ort_session.run(None, {'input': input_np})
    return outputs[0]

# Test the converted model
onnx_output = test_onnx_inference("model.onnx", sample_input)

Convert to TensorFlow Lite

import tensorflow as tf

def pytorch_to_tflite(onnx_path, tflite_path):
    """
    Convert ONNX model to TensorFlow Lite
    """
    # Convert ONNX to TensorFlow
    from onnx_tf.backend import prepare
    import onnx

    onnx_model = onnx.load(onnx_path)
    tf_rep = prepare(onnx_model)
    tf_rep.export_graph("temp_tf_model")

    # Convert to TensorFlow Lite
    converter = tf.lite.TFLiteConverter.from_saved_model("temp_tf_model")

    # Apply optimizations
    converter.optimizations = [tf.lite.Optimize.DEFAULT]

    # Convert model
    tflite_model = converter.convert()

    # Save the model
    with open(tflite_path, 'wb') as f:
        f.write(tflite_model)

    print(f"TensorFlow Lite model saved to {tflite_path}")

# Convert to TensorFlow Lite
pytorch_to_tflite("model.onnx", "model.tflite")

3. Mobile Deployment

Android Deployment

// Android Java code for PyTorch Mobile
public class ModelInference {
    private Module model;

    public ModelInference(String modelPath) {
        model = LiteModuleLoader.load(modelPath);
    }

    public float[] predict(Bitmap bitmap) {
        // Preprocess image
        Tensor inputTensor = TensorImageUtils.bitmapToFloat32Tensor(
            bitmap,
            TensorImageUtils.TORCHVISION_NORM_MEAN_RGB,
            TensorImageUtils.TORCHVISION_NORM_STD_RGB
        );

        // Run inference
        Tensor outputTensor = model.forward(IValue.from(inputTensor)).toTensor();

        // Get results
        return outputTensor.getDataAsFloatArray();
    }
}

iOS Deployment (Swift)

// iOS Swift code for PyTorch Mobile
import LibTorch

class ModelInference {
    private var model: TorchModule

    init(modelPath: String) {
        model = TorchModule(fileAtPath: modelPath)!
    }

    func predict(image: UIImage) -> [Float] {
        // Preprocess image
        guard let pixelBuffer = image.pixelBuffer() else { return [] }
        guard let inputTensor = TorchTensor.fromPixelBuffer(pixelBuffer) else { return [] }

        // Run inference
        guard let outputTensor = model.predict(inputs: [inputTensor]) else { return [] }

        // Get results
        return outputTensor[0].floatArray
    }
}

Python Mobile Preprocessing

def create_mobile_model(model, sample_input):
    """
    Create optimized model for mobile deployment
    """
    model.eval()

    # Convert to TorchScript
    traced_model = torch.jit.trace(model, sample_input)

    # Optimize for mobile
    optimized_model = optimize_for_mobile(traced_model)

    # Save mobile-optimized model
    optimized_model._save_for_lite_interpreter("mobile_model.ptl")

    return optimized_model

from torch.utils.mobile_optimizer import optimize_for_mobile

# Create mobile model
mobile_model = create_mobile_model(model, sample_input)

4. Raspberry Pi Deployment

# Raspberry Pi deployment script
import torch
import torchvision.transforms as transforms
from PIL import Image
import time
import psutil
import threading

class RaspberryPiInference:
    def __init__(self, model_path, device='cpu'):
        self.device = torch.device(device)
        self.model = torch.jit.load(model_path, map_location=self.device)
        self.model.eval()

        # Define preprocessing transforms
        self.transform = transforms.Compose([
            transforms.Resize((224, 224)),
            transforms.ToTensor(),
            transforms.Normalize(mean=[0.485, 0.456, 0.406],
                               std=[0.229, 0.224, 0.225])
        ])

        # Performance monitoring
        self.inference_times = []

    def preprocess_image(self, image_path):
        """Preprocess image for inference"""
        image = Image.open(image_path).convert('RGB')
        input_tensor = self.transform(image).unsqueeze(0)
        return input_tensor.to(self.device)

    def inference(self, image_path):
        """Run inference on image"""
        start_time = time.time()

        # Preprocess
        input_tensor = self.preprocess_image(image_path)

        # Inference
        with torch.no_grad():
            outputs = self.model(input_tensor)
            predictions = torch.nn.functional.softmax(outputs[0], dim=0)

        inference_time = time.time() - start_time
        self.inference_times.append(inference_time)

        return predictions.cpu().numpy(), inference_time

    def get_system_stats(self):
        """Get system performance statistics"""
        return {
            'cpu_percent': psutil.cpu_percent(),
            'memory_percent': psutil.virtual_memory().percent,
            'temperature': self.get_cpu_temperature()
        }

    def get_cpu_temperature(self):
        """Get CPU temperature (Raspberry Pi specific)"""
        try:
            with open('/sys/class/thermal/thermal_zone0/temp', 'r') as f:
                temp = float(f.read()) / 1000.0
            return temp
        except:
            return None

# Usage example
if __name__ == "__main__":
    # Initialize inference engine
    inference_engine = RaspberryPiInference("model.pt")

    # Run inference
    predictions, inference_time = inference_engine.inference("test_image.jpg")

    print(f"Inference time: {inference_time:.3f} seconds")
    print(f"Top prediction: {predictions.max():.3f}")
    print(f"System stats: {inference_engine.get_system_stats()}")

5. NVIDIA Jetson Deployment

# NVIDIA Jetson optimized deployment
import torch
import tensorrt as trt
import pycuda.driver as cuda
import pycuda.autoinit
import numpy as np

class JetsonTensorRTInference:
    def __init__(self, onnx_model_path, trt_engine_path=None):
        self.onnx_path = onnx_model_path
        self.engine_path = trt_engine_path or onnx_model_path.replace('.onnx', '.trt')

        # Build or load TensorRT engine
        if not os.path.exists(self.engine_path):
            self.build_engine()

        self.engine = self.load_engine()
        self.context = self.engine.create_execution_context()

        # Allocate GPU memory
        self.allocate_buffers()

    def build_engine(self):
        """Build TensorRT engine from ONNX model"""
        logger = trt.Logger(trt.Logger.WARNING)
        builder = trt.Builder(logger)
        network = builder.create_network(1 << int(trt.NetworkDefinitionCreationFlag.EXPLICIT_BATCH))
        parser = trt.OnnxParser(network, logger)

        # Parse ONNX model
        with open(self.onnx_path, 'rb') as model:
            if not parser.parse(model.read()):
                for error in range(parser.num_errors):
                    print(parser.get_error(error))
                return None

        # Build engine
        config = builder.create_builder_config()
        config.max_workspace_size = 1 << 28  # 256MB
        config.set_flag(trt.BuilderFlag.FP16)  # Enable FP16 precision

        engine = builder.build_engine(network, config)

        # Save engine
        with open(self.engine_path, 'wb') as f:
            f.write(engine.serialize())

        return engine

    def load_engine(self):
        """Load TensorRT engine"""
        runtime = trt.Runtime(trt.Logger(trt.Logger.WARNING))
        with open(self.engine_path, 'rb') as f:
            return runtime.deserialize_cuda_engine(f.read())

    def allocate_buffers(self):
        """Allocate GPU memory buffers"""
        self.bindings = []
        self.inputs = []
        self.outputs = []

        for binding in self.engine:
            shape = self.engine.get_binding_shape(binding)
            size = trt.volume(shape) * self.engine.max_batch_size
            dtype = trt.nptype(self.engine.get_binding_dtype(binding))

            # Allocate host and device buffers
            host_mem = cuda.pagelocked_empty(size, dtype)
            device_mem = cuda.mem_alloc(host_mem.nbytes)

            self.bindings.append(int(device_mem))

            if self.engine.binding_is_input(binding):
                self.inputs.append({'host': host_mem, 'device': device_mem})
            else:
                self.outputs.append({'host': host_mem, 'device': device_mem})

    def inference(self, input_data):
        """Run TensorRT inference"""
        # Copy input data to GPU
        np.copyto(self.inputs[0]['host'], input_data.ravel())
        cuda.memcpy_htod(self.inputs[0]['device'], self.inputs[0]['host'])

        # Run inference
        self.context.execute_v2(bindings=self.bindings)

        # Copy output data from GPU
        cuda.memcpy_dtoh(self.outputs[0]['host'], self.outputs[0]['device'])

        return self.outputs[0]['host']

# Usage for Jetson
jetson_inference = JetsonTensorRTInference("model.onnx")

6. Performance Optimization

Benchmarking Script

import time
import numpy as np
import torch
import psutil
from contextlib import contextmanager

@contextmanager
def timer():
    """Context manager for timing code execution"""
    start = time.perf_counter()
    yield
    end = time.perf_counter()
    print(f"Execution time: {end - start:.4f} seconds")

class ModelBenchmark:
    def __init__(self, model, input_shape, device='cpu'):
        self.model = model.to(device)
        self.device = device
        self.input_shape = input_shape

    def benchmark_inference(self, num_runs=100, warmup_runs=10):
        """Benchmark model inference performance"""
        # Generate random input
        dummy_input = torch.randn(self.input_shape).to(self.device)

        # Warmup runs
        self.model.eval()
        with torch.no_grad():
            for _ in range(warmup_runs):
                _ = self.model(dummy_input)

        # Benchmark runs
        inference_times = []
        memory_usage = []

        for i in range(num_runs):
            # Monitor memory before inference
            if self.device == 'cuda':
                torch.cuda.empty_cache()
                memory_before = torch.cuda.memory_allocated()
            else:
                memory_before = psutil.Process().memory_info().rss

            # Time inference
            start_time = time.perf_counter()
            with torch.no_grad():
                output = self.model(dummy_input)

            if self.device == 'cuda':
                torch.cuda.synchronize()

            end_time = time.perf_counter()

            # Monitor memory after inference
            if self.device == 'cuda':
                memory_after = torch.cuda.memory_allocated()
            else:
                memory_after = psutil.Process().memory_info().rss

            inference_times.append(end_time - start_time)
            memory_usage.append(memory_after - memory_before)

        # Calculate statistics
        stats = {
            'mean_time': np.mean(inference_times),
            'std_time': np.std(inference_times),
            'min_time': np.min(inference_times),
            'max_time': np.max(inference_times),
            'fps': 1.0 / np.mean(inference_times),
            'mean_memory': np.mean(memory_usage),
            'max_memory': np.max(memory_usage)
        }

        return stats

    def profile_model(self):
        """Profile model to identify bottlenecks"""
        dummy_input = torch.randn(self.input_shape).to(self.device)

        with torch.profiler.profile(
            activities=[torch.profiler.ProfilerActivity.CPU, torch.profiler.ProfilerActivity.CUDA],
            record_shapes=True,
            profile_memory=True,
            with_stack=True
        ) as profiler:
            with torch.no_grad():
                self.model(dummy_input)

        # Print profiling results
        print(profiler.key_averages().table(sort_by="cuda_time_total", row_limit=10))

        return profiler

# Usage example
benchmark = ModelBenchmark(model, (1, 3, 224, 224), device='cpu')
stats = benchmark.benchmark_inference()
print(f"Average inference time: {stats['mean_time']:.4f}s")
print(f"FPS: {stats['fps']:.2f}")

Memory Optimization

def optimize_memory_usage(model):
    """Apply memory optimization techniques"""

    # Enable memory efficient attention (for transformers)
    if hasattr(model, 'enable_memory_efficient_attention'):
        model.enable_memory_efficient_attention()

    # Use gradient checkpointing during training
    if hasattr(model, 'gradient_checkpointing_enable'):
        model.gradient_checkpointing_enable()

    # Fuse operations where possible
    model = torch.jit.optimize_for_inference(torch.jit.script(model))

    return model

def batch_inference(model, data_loader, batch_size=1):
    """Perform batch inference with memory management"""
    model.eval()
    results = []

    with torch.no_grad():
        for batch in data_loader:
            # Process in smaller chunks if needed
            if batch.size(0) > batch_size:
                for i in range(0, batch.size(0), batch_size):
                    chunk = batch[i:i+batch_size]
                    output = model(chunk)
                    results.append(output.cpu())

                    # Clear GPU cache
                    if torch.cuda.is_available():
                        torch.cuda.empty_cache()
            else:
                output = model(batch)
                results.append(output.cpu())

    return torch.cat(results, dim=0)

7. Best Practices

Model Deployment Checklist

class DeploymentValidator:
    def __init__(self, original_model, optimized_model, test_input):
        self.original_model = original_model
        self.optimized_model = optimized_model
        self.test_input = test_input

    def validate_accuracy(self, tolerance=1e-3):
        """Validate that optimized model maintains accuracy"""
        self.original_model.eval()
        self.optimized_model.eval()

        with torch.no_grad():
            original_output = self.original_model(self.test_input)
            optimized_output = self.optimized_model(self.test_input)

        # Check if outputs are close
        if torch.allclose(original_output, optimized_output, atol=tolerance):
            print("✓ Accuracy validation passed")
            return True
        else:
            print("✗ Accuracy validation failed")
            diff = torch.abs(original_output - optimized_output).max().item()
            print(f"Maximum difference: {diff}")
            return False

    def validate_performance(self):
        """Compare performance metrics"""
        # Benchmark both models
        original_benchmark = ModelBenchmark(self.original_model, self.test_input.shape)
        optimized_benchmark = ModelBenchmark(self.optimized_model, self.test_input.shape)

        original_stats = original_benchmark.benchmark_inference(num_runs=50)
        optimized_stats = optimized_benchmark.benchmark_inference(num_runs=50)

        speedup = original_stats['mean_time'] / optimized_stats['mean_time']
        memory_reduction = (original_stats['mean_memory'] - optimized_stats['mean_memory']) / original_stats['mean_memory'] * 100

        print(f"Performance improvement: {speedup:.2f}x speedup")
        print(f"Memory reduction: {memory_reduction:.1f}%")

        return {
            'speedup': speedup,
            'memory_reduction': memory_reduction,
            'original_fps': original_stats['fps'],
            'optimized_fps': optimized_stats['fps']
        }

    def check_model_size(self):
        """Compare model file sizes"""
        # Save both models temporarily
        torch.save(self.original_model.state_dict(), 'temp_original.pth')
        torch.jit.save(torch.jit.script(self.optimized_model), 'temp_optimized.pt')

        import os
        original_size = os.path.getsize('temp_original.pth')
        optimized_size = os.path.getsize('temp_optimized.pt')

        size_reduction = (original_size - optimized_size) / original_size * 100

        print(f"Original model size: {original_size / 1024 / 1024:.2f} MB")
        print(f"Optimized model size: {optimized_size / 1024 / 1024:.2f} MB")
        print(f"Size reduction: {size_reduction:.1f}%")

        # Clean up temporary files
        os.remove('temp_original.pth')
        os.remove('temp_optimized.pt')

        return size_reduction

# Example usage
validator = DeploymentValidator(model, quantized_model, sample_input)
validator.validate_accuracy()
performance_metrics = validator.validate_performance()
size_reduction = validator.check_model_size()

Error Handling and Logging

import logging
from functools import wraps

def setup_logging():
    """Setup logging for deployment"""
    logging.basicConfig(
        level=logging.INFO,
        format='%(asctime)s - %(name)s - %(levelname)s - %(message)s',
        handlers=[
            logging.FileHandler('model_deployment.log'),
            logging.StreamHandler()
        ]
    )
    return logging.getLogger(__name__)

def handle_inference_errors(func):
    """Decorator for handling inference errors"""
    @wraps(func)
    def wrapper(*args, **kwargs):
        try:
            return func(*args, **kwargs)
        except torch.cuda.OutOfMemoryError:
            logging.error("CUDA out of memory. Try reducing batch size.")
            torch.cuda.empty_cache()
            raise
        except Exception as e:
            logging.error(f"Inference error: {str(e)}")
            raise
    return wrapper

class RobustInference:
    def __init__(self, model_path, device='cpu'):
        self.logger = setup_logging()
        self.device = torch.device(device)

        try:
            self.model = torch.jit.load(model_path, map_location=self.device)
            self.model.eval()
            self.logger.info(f"Model loaded successfully on {device}")
        except Exception as e:
            self.logger.error(f"Failed to load model: {e}")
            raise

    @handle_inference_errors
    def inference(self, input_data):
        """Robust inference with error handling"""
        start_time = time.time()

        with torch.no_grad():
            output = self.model(input_data)

        inference_time = time.time() - start_time
        self.logger.info(f"Inference completed in {inference_time:.3f}s")

        return output

Conclusion

This guide provides a comprehensive approach to deploying PyTorch models on edge devices. Key takeaways:

1. Model Optimization: Always quantize and prune models before deployment
2. Format Selection: Choose the right format (TorchScript, ONNX, TensorRT) based on your target device
3. Performance Monitoring: Continuously monitor inference time, memory usage, and accuracy
4. Device-Specific Optimization: Leverage device-specific optimizations (TensorRT for NVIDIA, Core ML for iOS)
5. Robust Deployment: Implement proper error handling and logging for production systems

Remember to validate your optimized models thoroughly before deployment and monitor their performance in production environments.
